JAC T9 Right-Hand Drive All-Electric Pickup
Overview
Performance
Configuration
| 参数中文名 | 参数英文名 | 参数值 |
| 品牌 | Brand | JAC |
| 车系 | Series | T9EV |
| 车型号 | Product Model | HFC1037D5EV1 |
| 配置版本 | Trim Level | Advance |
| 结构区别号 | Design Code | X7310 |
| 驾驶室 | Cabin | DOUBLE CABIN |
| 前八位VIN | VIN | LJ1EPABR |
| 镀锌板 | Galvanized Sheet | ● |
| 货箱内尺寸（长×宽×高） | Cargo Box Length x Width x Height（mm） | 1520×1590×470 |
| 轴距(mm) | Wheelbase(mm) | 3110 |
| 轮距（前/后） | Track (Front / Rear )（mm） | 1610/1610 |
| 前悬／后悬 | Overhang–Front/Rear（mm） | 945/1275 |
| 最小离地间隙 | Min Ground Clearance（mm） | 205 |
| 最小转弯半径（m） | Min Turing Radius（m） | 6.6 |
| 接近角/离去角 | Approach / Departure Angle（°） | 27°/21° |
| 纵向通过角 | Ramp Breakover Angle（°） | — |
| 最大涉水深度 | Max Weding Depth（mm） | — |
| 整备质量（kg） | Curb Weight(kg) | 2350 |
| 载质量（kg） | Payload（kg） | 910 |
| 最大结合总质量 | Gross Combined Mass（kg） | — |
| 拖挂质量(拖车带制动)（kg） | Towing Capacity With Trailer Brakes（kg） | — |
| 拖挂质量(拖车不带制动)（kg） | Towing Capacity Without Trailer Brakes（kg） | 750 |
| 拖挂球头质量（kg） | Maximum Tow Ball Download（kg） | — |
| 前桥最大载荷（kg） | Max Front Axle Load（kg） | 1300 |
| 后桥最大载荷（kg） | Max Rear Axle Load（kg） | 2000 |
| 电池类型 | Battery Type | Lithium iron phosphate |
| 电池品牌 | Battery Brand | CATL |
| 电池能量（kWh） | Battery Capacity（kWh） | 88.02 |
| 电池系统能量密度（Wh/kg） | Battery Energy Density（Wh/kg） | 150 |
| 额定工作电压（V） | Rated Voltage（V） | 328.44 |
| 工作电压范围（V） | Operating Voltage Range（V） | 255～372.3 |
| 单体容量（Ah） | Unit Capacity（Ah） | 268 |
| 成组形式 | Group Form | 1P102S |
| 冷却方式 | Cooling Method | liquid cooling |
| V2L对外放电 | Vehicle To Load（V2L） | ● |
| 充电接口类型 | Charging Port Type | CCS2 |
| 快充时间（h） | DC Charging Time（Min）15%-100% | 40 |
| 快充倍率（C） | DC Charging Ratio（C） | 1C |
| 慢充时间（h） | AC Charging Time（h）15%-100% | 14.7 |
| 慢充功率（kW） | AC Charging Power（kW） | 6.6 |
| 车载充电机功率 | Car Charger Power（kW） | — |
| 电机类型 | Motor Type | Permanent magnet synchronous |
| 电机型号 | Motor Model | TZ180XS137 |
| 额定功率（kW） | Rated Max Power（kW） | 26 |
| 额定扭矩（Nm） | Rated Torque（Nm） | 70 |
| 峰值功率（kW） | Peak Power（kW） | 70 |
| 峰值扭矩（Nm） | Peak Torque（Nm） | 176 |
| 减速器速比 | Reduction Ratio | 10.89 |
| 电机类型 | Motor Type | Permanent magnet synchronous |
| 电机型号 | Motor Model | TZ200XSY |
| 额定功率（kW） | Rated Max Power（kW） | 70 |
| 额定扭矩（Nm） | Rated Torque（Nm） | 150 |
| 峰值功率（kW） | Peak Power（kW） | 150 |
| 峰值扭矩（Nm） | Peak Torque（Nm） | 340 |
| 减速器速比 | Reduction Ratio | 13.17 |
| 驾驶模式切换（标准、经济、运动、雪地、越野） | Drive Mode Switch(Normal/ECO /Sport /Snow/Off-road) | ● |
| 驾驶模式切换（标准、经济） | Drive Mode Switch(Normal/ECO ） | — |
| 0-100km/h加速时间 | Accelerating time (0－100km/h) (s) | 8.5 |
| 最高车速(km/h) | Max Speed(km/h) | 140 |
| 最大爬坡度（℅） | Max Gradeability（%） | 30 |
| NEDC续航（km） | NEDC Range（km） | 371 |
| CLTC续航（km） | CLTC Range（km） | 400 |
| WLTP续航（km） | WLTP Range（km） | 330 |
| 双叉臂螺旋弹簧独立前悬架 | Double Wishbone Independent Suspension With Coil Spring | ● |
| 整体桥式钢板弹簧非独立后悬架 | Non-independent Leaf Spring Rigid Axle Rear Suspension | ● |
| 整体桥式多连杆非独立后悬架 | Non-independent Multi-link Rigid Axle Rear Suspension | — |
| 钢板弹簧数（片） | Number Of Leaf Springs | 2+3 |
| 电动液压转向助力 | Electronic Hydraulic Power Steering | ● |
| 前制动器类型 | Front Brake | Disc |
| 后制动器类型 | Rear Brake | Disc |
| 手刹 | Hand Brake | — |
| 电子驻车 | Electronic Parking Brake | ● |
| 自动驻车 | Auto Hold | ● |
| 电池包下护板 | Battery Pack Undertray | — |
| 钢轮辋 | Steel Rim | — |
| 铝合金轮辋 | Aluminium Alloy Rim | ● |
| 备胎钢轮辋 | Spare Tire With Steel Rim | ● |
| 备胎规格 | Spare Tire Type | 265/60 R18 |
| 补胎精灵 | Tire Repair Elves | ● |
| ABS防抱死制动系统 | Anti-Lock Braking System(ABS) | ● |
| EBD电子制动力分配系统 | Electronic Brake-Force Distribution (EBD) | ● |
| BOS刹车优先 | Brake Override System(BOS) | ● |
| ARB电机堵转防溜坡系统 | Anti-Roll Back（ARB） | ● |
| HHC坡道辅助系统 | Hill-start Hold Control(HHC) | ● |
| 车辆行人声音警告系统 | Vehicle Sound for Pedestrians system（VSP） | |
| HBA液压制动辅助 | Hydraulic Brake Assist (HBA) | ● |
| TCS牵引力控制系统 | Traction Control System(TCS) | ● |
| VDC车辆动态控制系统 | Vehicle Dynamics Control(VDC) | ● |
| ESC车身稳定系统 | Electronic Stability Control(ESC) | ● |
| E-CALL紧急呼叫 | E-CALL | — |
| 胎压监测 | Tire Pressure Monitoring | ● |
| 主副驾驶安全气囊 | Driver And Front Passenger Airbags | ● |
| 前排中央安全气囊 | Front Centre Airbag | ● |
| 前排侧气囊 | Front Side Airbags | ● |
| 前排侧气帘 | Front Curtain Airbags | — |
| 前排安全带高度可调 | Front SeatBelts Height Adjustment | ● |
| 前排预紧式安全带 | Front Pre-tensioner Seatbelts | ● |
| 后排两侧三点式安全带 | Rear Side Seat With 3-Point Seatbelts | ● |
| 后排中间三点式安全带 | Rear Middle Seat With 3- Point Seatbelts | ● |
| 主驾驶安全带未系报警 | Driver Seatbelt Unfastened Warning | ● |
| 副驾驶安全带未系提醒 | Front Passenger Seatbelt Unfastened Warning | ● |
| 后排安全带未系提醒 | Rear Seatbelt Unfastened Warning | — |
| 后排中间座椅头枕 | Rear Middle Seat Headrest | ● |
| 车内中控锁 | Central Locking System | ● |
| 电动门锁 | Electric Door Locks | ● |
| 车门自动落锁 | Automatic Door Locks | ● |
| 车门未关提醒 | Door Ajar Warning | ● |
| 遥控中央门锁 | Remote Central Locking | ● |
| 无钥匙进入及启动系统 | Smart Keyless Entry With Push Button Start | ● |
| 电动尾门锁 | Electronic Locking Tailgate | — |
| ISOFIX儿童座椅接口 | Child Restraint System(ISOFIX) | ● |
| 儿童锁 | Child Safety Locks | ● |
| 碰撞后自动解锁功能 | Auto Unlock After Collision | ● |
| 碰撞自动断电保护 | Automatic Power Off Protection After Collision | ● |
| 低温充电预热 | Low Temperature Charge Preheating | ● |
| LDW车道偏移预警 | Lane Departure Warning(LDW) | — |
| LKA车道保持辅助 | Lane Keeping Assist(LKA) | — |
| ELK紧急车道保持 | Emergency Lane Keeping(ELK) | — |
| BSD盲点监测系统 | Blind Spot Detection(BSD) | ● |
| RCTA倒车侧后方预警系统 | Rear Cross Traffic Alert（RCTA) | ● |
| FCW前碰撞预警系统 | Forward Collision Warning(FCW) | — |
| RCW后碰撞预警系统 | Rear Collision Warning(RCW) | ● |
| DOW开门预警系统 | Door Open Warning(DOW) | ● |
| TJA交通拥堵辅助系统 | Traffic Jam Assistant(TJA) | — |
| DMS驾驶员监测系统 | Driver Monitor System(DMS) | — |
| AEB自动紧急刹车系统 | Autonomous Emergency Braking(AEB) | — |
| ICA集成式巡航辅助 | Integrated Cruise Assist(ICA) | — |
| IHBC智能远光灯控制系统 | Intelligence High Beam Control(IHBC) | — |
| 车辆行人声音警告系统 | Vehicle Sound for Pedestrians system（VSP） | ● |
| 前雷达 | Front Parking Sensors | — |
| 倒车雷达 | Rear Parking Sensors | ● |
| 倒车影像 | Reversing View Camera | ● |
| 360°全景影像 | 360°Panoramic View Camera | — |
| 定速巡航 | Cruise Control | ● |
| 喷涂式货箱宝 | Spray-In Bedliner | ● |
| 内衬式货箱宝 | Drop In Bedliner | — |
| 黑色SMC龙门架 | Black SMC Roll Bar | — |
| 黑色金属龙门架 | Black Metal Roll Bar | ● |
| 货箱外绳钩 | External Cargo Rope Hook | — |
| 货箱内绳钩 | Tub Cargo Tie Down Hooks | ●（4） |
| 尾门升降辅助 | Tailgate With Lift Assistance | — |
| T8黑色横幅格栅 | T8 Black Horizontal Grille | — |
| T9中国鼎横幅格栅 | T9 Chinese Ding Horizontal Grille | ● |
| 蓝色JAC字标 | Blue JAC Logo | ● |
| 镀铬JAC字标 | Chrome JAC Logo | ○ |
| 红色JAC字标 | Red JAC Logo | — |
| 黑色JAC字标 | Black JAC Logo | — |
| 车身同色前保险杠 | Body-Colored Front Bumper | ● |
| 车身同色塑料后保险杠 | Body-Colored Plastic Rear Bumper | — |
| 黑色塑料后保险杠 | Black Plastic Rear Bumper | ● |
| 塑料侧踏板 | Plastic Side Step | — |
| 金属侧踏板 | Metal Side Step | ● |
| 车身同色外后视镜 | Body-Colored Exterior Mirrors | — |
| 镀铬外后视镜 | Chrome Exterior Mirrors | ● |
| 黑色外后视镜 | Black Exterior Mirrors | — |
| 外后视镜电动调节 | Power Adjustable Exterior Mirrors | ● |
| 外后视镜电加热 | Heated Exterior Mirrors | ● |
| 外后视镜电动折叠 | Power Folding Exterior Mirrors | ● |
| 黑色皮纹门把手 | Black Door Handle | — |
| 亮黑门把手 | Bright Black Door Handle | — |
| 镀铬门把手 | Grille Door Handle | ● |
| 黑色车顶行李架 | Black Roof Rails | — |
| 银色车顶行李架 | Silver Roof Rails | — |
| 电动天窗 | Power Sunroof | — |
| 鲨鱼鳍天线 | Shark Antenna | ● |
| 杆式天线 | Whip Antenna | — |
| 后排隐私玻璃 | Rear Privacy Glass | ● |
| 后风窗除霜 | Heated Rear Window | ● |
| 引擎盖气撑杆 | Air Supporting Rod Of Hood | ● |
| LED大灯 | LED Headlights | ● |
| 卤素日间行车灯 | Halogen Daytime Running Light | — |
| LED日间行车灯 | LED Daytime Running Light | ● |
| LED后尾灯 | LED Tail Light | ● |
| 高位刹车灯 | High-Mounted Brake Light | ● |
| 前雾灯 | Front Fog Light | ● |
| 后雾灯 | Rear Fog Light | ● |
| 大灯高度可调 | Adjustable Headlights Height | ● |
| 大灯自动点亮 | Auto Headlight | ● |
| 大灯延时关闭 | Follow-Me-Home Headlights | ● |
| 转向辅助照明 | Steering Light Assist | ● |
| 64色内饰氛围灯 | 64 Color Ambient Lights | ● |
| 全黑内饰 | All Black Interior | ● |
| 黑棕内饰 | Black And Brown Interior | — |
| 软包内饰 | Leather Accented Interior | ● |
| 前排阅读灯 | Front Reading Light | ● |
| 后排阅读灯 | Rear Reading Light | ● |
| 眼镜盒 | Sunglass Box | ● |
| 主副驾驶遮阳板 | Driver And Front Passenger Sun visors | ● |
| 主驾遮阳板化妆镜 | Driver Sun Visor With Vanity Mirror | ● |
| 副驾遮阳板化妆镜 | Front Passenger Sun Visor With Vanity Mirror | ● |
| 塑料方向盘 | Plastic Steering Wheel | — |
| 皮革方向盘 | Leather Bound Steering Wheel | ● |
| 多功能方向盘 | Multi-Functional Steering Wheel | ● |
| 方向盘上下调节 | Steering Wheel Tilt Adjustment | ● |
| 方向盘前后调节 | Steering Wheel Telescopic Adjustment | — |
| B柱登车扶手 | B-Pillar Grab Handle | ● |
| 后排衣帽钩 | Rear Seat Coat Hook | ● |
| 电动玻璃 | Power Window | ● |
| 锁车自动升窗 | Auto Window Up With Locking | ● |
| 驾驶位玻璃一键降 | One-Touch Down For Driver's Window | — |
| 四门车窗一键升降+防夹 | Automatic Up/Down+Anti-Clamp For All Windows | ● |
| 内后视镜手动防眩目 | Manual Anti-glare Of Interior Mirror | ● |
| 内后视镜自动防眩目 | Automatic Anti-glare Of Interior Mirror | — |
| 可变间歇式雨刮器 | Variable Intermittent Windscreen Wipers | ● |
| 感应雨刷 | Rain Sensing Windscreen Wipers | — |
| 手动空调 | Manual Air Conditioning | — |
| 自动空调 | Automatic Air Conditioning | ● |
| 中央扶手箱出风口 | Central Armrest Box Air Outlet | ● |
| 后排出风口 | Rear Vents | ● |
| 前排中央扶手 | Front Armrest | ● |
| 后排中央扶手及杯架 | Rear Armrest With Cup Holders | ● |
| 织物座椅 | Fabric Seats | — |
| 驾驶员座椅手动调节 | Manual Driver’s Seat Adjustment | — |
| 驾驶员座椅电动调节 | Electric Driver’s Seat Adjustment | ●（6） |
| 副驾驶座椅手动调节 | Manual Front Passenger's Seat Adjustment | ●（4） |
| 副驾驶座椅电动调节 | Electric Front Passenger's Seat Adjustment | — |
| 60:40折叠式第二排座椅 | 60:40 Folding 2nd Row Seats | — |
| 前排座椅加热 | Heated Front Seats | — |
| 组合仪表亮度调节 | Instrument Cluster Dimmer Switch | ● |
| DAB数字广播 | DAB+ Digital Radio | ● |
| 蓝牙 | Bluetooth Connectivity | ● |
| T-BOX | T-BOX | — |
| 有线苹果/安卓手机互联 | Wired Apple CarPlay/Android Auto Smartphone Connectivity | ● |
| 无线苹果/安卓手机互联 | Wireless Apple CarPlay/Android Auto Smartphone Connectivity | — |
| 扬声器数量 | Speakers | 6 |
| 前排Type-C接口 | Front Type-C Port | — |
| 前排USB接口 | Front USB Port | ●（2） |
| 前排12V电源接口 | Front 12V Accessory Socket | ● |
| 前排无线充电 | Wireless Charging | ● |
| 后排USB接口 | Rear USB Port | ● |
| 后排Type-C接口 | Rear Type-C Port | ● |
| 后排220V电源接口 | Rear 220V Accessory Socket | — |
| 前救援钩 | Front Recovery Hook | ● |
| 后救援钩 | Rear Recovery Hook | — |
| 后拖车杠 | Tow bar | — |
| 国标充电线（GB/T,AC） | Charging Cable（GB/T,AC） | — |
| 欧标充电线（CCS2,AC） | Charging Cable（CCS2,AC） | ● |
| 瑞标充电线(Type 2,AC) | Charging Cable（Type 2,AC） | — |
| 充电转换线(GB-CCS2) | Charging conversion cable(GB-CCS2) | — |
