The Limi technology team and Swiss Constellium jointly developed and applied the fourth generation "EcoRange" aluminum body technology, which has been developed by Mercedes Benz MAN、 Commercial vehicle manufacturers such as Scania and Volvo have applied it on over 70000 buses worldwide.
| 立米汽车制造（威海）有限公司 Limi Automobile Manufacturing (Weihai) Co., Ltd. | |||||
| 产品型号/Model | BM6123YBEV | ||||
| COMPLETE VEHICLE SPECIFICATION | |||||
| 基本参数 | 长（mm） | Length | 12300 |
| |
| 宽（mm） | Width | 2540 | |||
| 高（mm） | Height | 3600 | |||
| 整备质量（Kg） | Curb weight | 12000 | |||
| 最大总质量（Kg） | Maximum total mass | 18000 | |||
| 最大乘员数 | Maximum passengers capacity | 绒布座椅至多：60+1 Fabric seats maximum: 60+1 | |||
| 塑料座椅： 65+1 Plastic seats: 65+1 | |||||
| 最高车速（Km/h） | Maximum speed | 100 | |||
| 最大爬坡度 | Maximum gradability | 20% | |||
| 最小离地间隙（mm） | Minimum ground clearance | 290 | |||
| 匀速续航（KM) | Constant speed endurance (KM) | 500KM | |||
| CHASSIS SPECIFICATION | |||||
| 类型 | 系统 | Items | 规格型号 | Specification | Remarks |
| 底盘配置 | 电机 | Motor | 160/280kW,永磁同步 | 160/280kW,PMSM | |
| 后桥 | Rear axle | 13T冲焊后桥，鼓式制动器 | 13T, Drum brake | ||
| 悬架系统 | Suspension | 板簧悬架,选装空气悬架 | Leaf spring suspension,Optional air suspension | ||
| 前桥 | Front axle | 6.5T工字梁式，盘式制动器 | 6.5T, disc brake | ||
| 轮胎 | Tyre | 295/80R22.5 | 295/80R22.5 | ||
| 钢圈 | Steel rim | 22.5x8.25，普通钢圈 | 22.5x8.25 | ||
| 转向系统 | Steering system | 液压助力转向 | Hydraulic power steering | ||
| 方向盘 | Steering wheel | 四幅，φ480mm | φ480mm | ||
| 制动系统 | Braking system | 双回路气制动 | Dual air circuit brake， spring energy storage parking brake | ||
| ABS | ABS | ABS | Made in China | ||
| 冷却系统 | Cooling system | 机械式传动 | Mechanic drive | ||
| 膨胀水箱 | Expansion water tank | 有 | Yes | ||
| 底架及其附件 | Frame and accessories | 全承载式 | Monocoque | ||
| 随车工具 | Tool kit | 有 | Yes | ||
| 其他 | Others | 根据客户要求并确认 | According to customer's request and to be confirmed | ||
| BODY SPECIFICATION | |||||
| 车身配置 | 驾驶方向 | Drive mode | 左舵 | LHD | |
| 前挡玻璃 | Front windshield | 夹胶玻璃,左右两片式 | Laminated glass, left and right two-piece | ||
| 后挡玻璃 | Rear windshield | 钢化玻璃 | Hardened glass | ||
| 侧窗玻璃 | Side window | 内嵌式推拉窗 | Embedded sliding window | ||
| 顶窗和换气扇 | Roof hatch | 2个带换气扇的安全顶窗 | 2 hatch with ventilation fan | ||
| 乘客门 | Passenger door | 电控气动外摆门（单门） | Electric Pneumatic Swinging Door (Single Door) | ||
| 侧舱门 | Side cabin door | 铝合金 | Aluminum alloy | ||
| 尾舱门 | Rear cabin door | 铝合金 | Aluminum alloy | ||
| 后视镜 | Rearview mirror | 普通后视镜 | As per standard | ||
| 地板 | Floor | 18mm竹胶地板 | Bamboo plywood floor,18mm | ||
| 地板革 | Floor cover | 国产石英砂地板革 | Silicon floor leather | ||
| 司机椅 | Driver's seat | 前后可调司机座椅, 带三点安全带 | Adjustable, with three-point belt | ||
| 乘客座椅 | Passenger seat | 53, 两点式安全带，绒布软垫 ，带扶手,坐垫离地高460mm | 53. Two point seat belt, velvet soft cushion, with armrest, seat cushion height 460mm above the ground | ||
| 遮阳帘 | Driver's Sunshield | 司机前、侧 | Front and side | ||
| 全车窗帘 | Curtain | 有 | Yes | ||
| 仪表台 | Instruments | 高级仪表台 | luxury type | ||
| 行李架 | Luggage rack | 双边开放式行李架 | Interior Luggage rack attwo sides, open type | ||
| 内饰 | Interior trimming | 豪华内饰 | Luxury type | ||
| 防护栏 | Protection bar | 有 | Yes | ||
| 台阶踏步灯 | Stair light | 有 | Yes | ||
| 车内灭火器 | Extinguisher | 2个4Kg | 2*4kg | ||
| 消防安全锤 | Safety hammer | 6个 | 6 | ||
| 油漆 | Paint | 普通漆 | Solid color paint | ||
| 卫生间 | Washroom | 选装 | Optional | ||
| 其他 | Others | 根据客户要求并确认 | According to customer's request and to be confirmed | ||
| ELECTRICAL SPECIFICATION | |||||
| 电气配置 | 电池组（磷酸铁锂电池） | Battery pack (lithium iron phosphate battery) | 564kwh 续航里程250-360KM | 564kwh range of 250-360KM | |
| 空调 | A/C | 单冷空调、顶置,选装 | Single cooling air conditioner, overhead mounted，Optional | ||
| 蓄电池 | Battery | 24V/100AH | 24V/100AH | ||
| 雨刮器 | Wiper | 普通雨刮 | As per standard | ||
| 仪表 | Instruments | 三级总线 | CAN | ||
| 电子钟 | Digital clock | 有 | Yes | ||
| 视频监控 | Monitoring system | 倒车+中门+司机+车内全景 +硬盘存储 | Reverse, F/R door, Driver, Interior | ||
| 后仓自动灭火装置 | Automatic fire extinguisher for rear cabin | 3只坛状灭火器 | 3 uits | ||
| 电动除霜器 | Electric defroster | 水暖除霜 | Water heat defroster | ||
| 前门遥控门锁 | Door remote controller | 有 | Yes | ||
| 倒车雷达 | Reverse Radar | 有 | Yes | ||
| 车载WIFI | WIFI | 有 | Yes | ||
| 充电口 | Charging receptacle | 国标 | Chinese Standard | ||
| 其他 | Others | 根据客户要求并确认 | According to customer's request and to be confirmed | ||
| USB | 按客户要求配60个 | Configure 60 units as per customer requirements. | |||
| 座椅靠背展示屏 | Seat backrest display screen | 按客户要求配60个 | Configure 60 units as per customer requirements. | ||
| 报价/Quotation | FOB青岛港 | FOB Qingdao Port | 人民币：1085000元 | RMB: 1085,000 yuan | 工厂负责到青岛港，超出部分加收费用The factory is responsible for delivery to Qingdao Port, with additional charges for any excess. |
| 选配项目及价格（人民币）Optional items and prices (in RMB) | |||||
| 项目内容 | Project content | 价格增加/Price increase | 价格扣减/Price deduction/ | ||
| 减配空调系统 | Downgraded air conditioning system | 45000元 | |||
| 选装空气悬架 | Optional air suspension | 30000 | |||
| 选装 卫生间 | Optional bathroom | 46000 | |||
| 质保/Warranty | 整车 Complete vehicle | 2年12万公里先到为准/2 years or 120,000km which comes first | |||
| 车身骨架 Vehicle body frame | 质保15年 15-year warranty | ||||
| 高压备件（电池，电机，电控等） High-voltage spare parts (battery, motor, electronic control, etc.) | 质保5年30万公里/HV parts(Battery, Motor, Controller,etc.) 5 years or 300,000km which comes first | ||||
| 造型Modeling | 可定制造型 Customizable styling | ||||
